Description
TronRFID TR0505 RFID Antenna-
The TronRFID TR0505 5.93" x 5.88" RFID Antenna is a right-hand circularly polarized RFID antenna that connects to UHF RFID readers to read and write to UHF RFID RAIN tags and labels. This antenna achieves high performance via high gain, low VSWR and low axial ratio, with options for ETSI frequency bands
The antenna is housed in high strength polycarbonate radome with thick aluminum backplate for strong durability in hard outdoor environments. The UHF RFID antenna is available with a flush mount option.
The TronRFID TR0505 RFID Antenna pairs well with TronRFID Antenna Cables to connect with various UHF RFID readers.
Frequently Asked Questions
What is the RFID Antenna?
An RFID antenna is a crucial component of an RFID system that transmits and receives radio waves to communicate with RFID tags. It enables the identification, tracking, and management of assets and inventory by capturing data from RFID tags within its read range.
What are the key features of the TronRFID TR0505 RFID Antenna?
The TronRFID TR0505 RFID Antenna boasts several key features:
- Compact and slim design for easy installation
- High gain and excellent read performance
- Wide frequency range compatibility
- Durable construction suitable for various environments
- Enhanced read accuracy and range
How does the TronRFID TR0505 RFID Antenna work?
The TronRFID TR0505 RFID Antenna operates by emitting radio waves that activate nearby RFID tags. When an RFID tag enters the antenna's field, it captures the signal and sends back its unique identification data to the RFID reader. The reader then processes this data for various applications, like tracking and inventory management.
What applications is the TronRFID TR0505 RFID Antenna suitable for?
The TronRFID TR0505 RFID Antenna is suitable for a wide range of applications, including:
- Retail inventory management
- Warehouse and logistics tracking
- Asset management in manufacturing
- Access control systems
- Healthcare equipment tracking
How durable is the TronRFID TR0505 RFID Antenna?
The TronRFID TR0505 RFID Antenna is built to be highly durable, featuring robust materials and construction that withstands various environmental conditions. It is designed for long-term use in both indoor and outdoor settings.
What are the typical read ranges of the TronRFID TR0505 RFID Antenna?
The typical read ranges of the TronRFID TR0505 RFID Antenna vary based on the RFID tags used and the environment. Generally, it offers an effective read range of up to several meters, providing reliable performance for various applications.
What are the environmental specifications for the TronRFID TR0505 RFID Antenna?
The environmental specifications for the TronRFID TR0505 RFID Antenna include:
- Operating temperature range: -22°C to +149°C
- Storage temperature range: -30°C to +65°C
- Protection rating: IP68, ensuring dust-tight and water-resistant performance
Additional Information
DIMENSIONS (L X W X H): |
150.7 mm x 149.4 mm x 14.5 mm (5.93" x 5.88" x 0.57") |
WEIGHT: |
0.23 kg / 0.51 lbs |
MOUNTING TYPE: |
Flush or 100 x 100 mm VESA mount using the four mounting holes |
CONNECTOR TYPE: |
SMA female (Jack) side connector |
Radome Material & Color: |
UV Resistant and Fire-Retardant WHITE ABS |
BACK PLATE: |
aluminum |
MOUNT STYLE: |
Flush |
ENVIRONMENTAL RATING: |
IP68 |
FREQUENCY RANGE: |
865MHz - 868MHz (ETSI) |
POLARIZATION: |
RHCP(RightHandCircularPolarization) |
FAR FIELD GAIN: |
5 dBiC typical |
VSWR: |
1.4 typical |
FAR FIELD 3-DB BEAM WIDTH: |
105° in both planes typical |
AXIAL RATIO: |
2dB Typical |
FRONT TO BACK RATIO: |
15dB |
INPUT IMPEDANCE: |
50 Ohms |
ANTI-STATIC PROTECTION: |
Yes, DC grounded |
MAXIMUM INPUT POWER: |
3 W |
download data sheet: |
https://rfid4ustore.in/content/TronRFID%20TR0505%20RFID%20Antenna.pdf |
